Onyx Helio
SKU:
MY1.009.120X120X9.069.111-1-1-1-1-1-2-1-2
📋
Copied!
| Color |
White
|
| Size |
120X120cm 09mm
|
| Material |
Porcelain
|
| Finishing |
Glossy
|
Collection Catalogue
View
Scan to View
Description
Onyx Helio 120x120cm | 09mm | Glossy Finish
Onyx Helio in 120x120cm brings the elegance of natural onyx stone to your space, enriched with a premium glossy surface for a luminous, high-end finish. With a 09mm thickness, this large-format tile offers exceptional durability and ease of maintenance, making it ideal for floors, walls, and feature surfaces. Its intricate veining and warm tones reflect light beautifully, adding depth and sophistication to living rooms, bathrooms, kitchens, and commercial interiors. Designed to combine style with practicality, Onyx Helio resists stains and scratches while enhancing luxury décor themes with its timeless appeal.
Technical Specifications
| CHARACTERISTIC |
STANDARD AS PER ISO-13006/EN14411 GROUP BIA |
MAYYAS VALUE |
TEST METHOD |
| REGULATORY PROPERTIES |
| Deviation in Length & Width: |
± 0.5 % |
± 0.2 % |
ISO- 10545-2 |
| Deviation in Thickness: |
± 5.0 % |
± 0.5 % |
ISO- 10545-2 |
| Straightness in side: |
± 0.5 % |
± 0.2 % |
ISO- 10545-2 |
| Rectangularity: |
± 0.5 % |
± 0.2 % |
ISO- 10545-2 |
| Surface flatness: |
± 0.5 % |
± 0.2 % |
ISO- 10545-2 |
| Color difference: |
Unaltered |
No change |
ISO- 10545-16 |
| Glossiness: |
As per mfg. |
Min 90 % |
GLOSSOMETER |
| STRUCTURAL PROPERTIES |
| Water absorption: |
< 0.50% |
< 0.05 % |
ISO- 10545-3 |
| Apparent density: |
> 2.0 g/cc |
> 2.10 g/cc |
DIN 51082 |
| MASSIVE MECHANICAL PROPERTIES |
| Modulus of rupture: |
Min. 35 N/mm2 |
Min. 40 N/mm2 |
ISO- 10545-4 |
| Breaking strength: |
Min. 1300 N |
Min. 2000 N |
ISO- 10545-4 |
| Impact resistance: |
As per mfg. |
Min. 0.55 |
ISO- 10545-5 |
| SURFACE MECHANICAL PROPERTIES |
| Surface abrasion resistance: |
As per mfg. |
Min. Class 3 |
ISO- 10545-7 |
| MOH’s hardness: |
As per mfg. |
Min. Class 4 |
EN 101 |
| THERMO HYGROMETRIC PROPERTIES |
| Frost resistance: |
No damage |
No damage |
ISO- 10545-12 |
| Thermal shock resistance: |
No damage |
No damage |
ISO- 10545-9 |
| Moisture expansion: |
Nil |
Nil |
ISO- 10545-10 |
| Thermal expansion (COE): |
Max 9.0 x 10-6 |
Max 6.5 x 10-6 |
ISO- 10545-8 |
| Crazing resistance: |
As per mfg. |
Min. 10 cycle |
ISO- 10545-11 |
| CHEMICAL PROPERTIES |
| Chemical resistance: |
No damage |
No damage |
ISO- 10545-13 |
| Stain resistance: |
Resistant |
Resistant |
ISO- 10545-14 |
| SAFTEY PROPERTIES |
| Slip resistance: |
As per mfg. |
> 0.40 |
ISO- 10545-17 |
| Fire resistance: |
As per mfg. |
Fireproof |
N. A |
| Lead & Cadmium given off by glazed tiles: |
As per mfg. |
Does not yield Pb & Cd |
ISO- 10545-15 |
| SIZE |
THICKNESS |
TILE / BOX |
COVERAGE AREA / BOX |
| 120X120cm : |
9mm |
2 Pcs |
2.88 Sq. M |
